| Frame |
TRAIL GEOMETRY, CARBON, ALLOY ROCKER. 120mm TRAVEL, 29" |
| Fork |
FOX 34 FLOAT FACTORY 29", KASHIMA, 15x110mm AXLE, TAPERED, FIT4, TRAVEL: 130mm, 3-POSITION LEVER |
| Shock |
FOX FLOAT DPS FACTORY, KASHIMA, LV, EVOL, 2 POS REMOTE, TRUNION 165x45, 25MM X 8MM HARDWARE |
| Rear derailleur |
SRAM XX1 EAGLE AXS, 12-SPEED |
| Shift lever |
SRAM EC AXS CONTROLLER RIGHT HAND ROCKER, 2 BUTTON, 12-SPEED |
| Crankset |
SRAM XX1 EAGLE BOOST, DUB, 32 TEETH |
| Bottom bracket |
SRAM DUB BSA |
| Cassette |
SRAM XG-1299 EAGLE, 10-52 TEETH, 12-SPEED GOLD |
| Chain |
SRAM CN-XX1 EAGLE GOLD |
| Brakes |
SHIMANO XTR TRAIL BR-M9020, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:180mm, R:180mm ROTORS, ICE TECH |
| Brake lever |
SHIMANO XTR TRAIL BL-M9120, ISPEC EV |
| Front hub |
DT SWISS WHEELSET SPLINE XMC-1501 CARBON, 15X110mm THRU AXLE |
| Rear hub |
DT SWISS WHEELSET SPLINE XMC-1501 CARBON, 12X148MM BOOST, THRU AXLE |
| Front tire |
ONZA PORCUPINE, KEVLAR FOLDABLE, TUEBELESS READY, 29x2.40" |
| Rear tire |
ONZA PORCUPINE, KEVLAR FOLDABLE, TUEBELESS READY, 29x2.40" |
| Stem |
RACE FACE TURBINE R, 0°ANGLE, 35mm CLAMP |
| Handlebar |
RACE FACE NEXT 35 CARBON, 760mm, 20mm RISE, 35mm CLAMP |
| Headset |
STSF17 INTEGRATED WITH CABLE INTEGRAGTION AND CABLE ENTRY DUSTCAP 1.5" UPPER AND LOWER BEARING |
| Seat post |
ROCK SHOX REVERB AXS, S:100MM, M & L: 125mm, XL: 150mm TRAVEL, WIRELESS REMOTE, 31.6mm |
| Saddle |
ERGON SM10 SPORT MAN |
| Weight |
12.1 KG |
