| Frame |
TRAIL GEOMETRY, ALLOY 6061, 120mm TRAVEL, DROPOUT FOR 148x12mm BOOST, 27.5" |
| Fork |
MANITOU MACHETE COMP, 27.5", TAPERED, AIR SPRING, 120mm TRAVEL, REBOUND, LOCKOUT |
| Shock |
MANITOU MARA, 165x45, D8x22mm, LOCK OUT, KIDS SOFT TUNE |
| Rear derailleur |
SHIMANO XT RD-M8100 SGS SHADOW PLUS DESIGN, 12-SPEED |
| Shift lever |
SHIMANO XT SL-M8100, DIRECT ATTACH TO BRAKE LEVER, ISPEC EV |
| Crankset |
SHIMANO FC-MT511, 2-PIECE CRANKSET, 32 TEETH |
| Bottom bracket |
SHIMANO BB-MT501 |
| Cassette |
SHIMANO CS-M6100, 10-51 THEETH, 12-SPEED |
| Chain |
SHIMANO CN-M6100 12-SPEED |
| Brakes |
SHIMANO BR-MT410, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:180mm, R:180mm ROTORS |
| Brake lever |
SHIMANO BL-M4100, ISPEC EV |
| Rims |
SUNRINGLE WHEELSET DUROC 30 COMP, TLR, 28 HOLES, INNER WIDTH 26mm, 27.5" |
| Front hub |
SUNRINGLE WHEELSET DUROC 30 COMP, 28 HOLES, 15x110mm THRU AXLE |
| Rear hub |
SUNRINGLE WHEELSET DOROC COMP, 28 HOLES, 12x148mm BOOST, THRU AXLE |
| Front tire |
ONZA PORCUPINE, WHT EDITION TRAIL, TUBLESS READY, WHT SKINWALL, 27.5x2.40 |
| Rear tire |
ONZA PORCUPINE, WHT EDITION TRAIL, TUBLESS READY, WHT SKINWALL, 27.5x2.40 |
| Stem |
KALLOY AS-M03, EXT 35mm, DIA 28.6mm, BAR BORE 31.8mm |
| Handlebar |
METS METAL B-203-J, 720mm, RISE 15mm, BACKSWEEP 9°, 31.8mm |
| Headset |
FSA NO.55R 1.5" / 558 |
| Seat post |
KIND SHOCK RAGEi, 31.6", 100mm TRAVEL, SHIMANO REMOT LEVER SL-MT500-IL |
| Saddle |
BIXS VL-1A47 |
| Frame size |
27.5" |
| Weight |
14.4 KG |
