Discover your flow on long trail tours. Thanks to its sensitive sensor technology and individual adjustability, the Shimano EP8 motor is known for its natural riding feeling. Get into the flow and enjoy the balanced riding characteristics of the Sign-E.
CHF 4,890.00 CHF 5,790.00
Silver Stealth
Which size fits me?

Frame sizes
149 – 163 cm: S
159 – 178 cm cm: M
174 - 188 cm: L
185 - 200 cm: XL

Where to test and buy?

BIXS retailer directory →

Tax included. Shipping calculated at checkout.
Sign-E23 (Sale)
Sign-E23 (Sale)
Sign-E23 (Sale)

Sign-E

Trails, Trails, Trails.

Learn more about the Sign-E +

Specifications Sign-E23

Frame E-TRAIL GEOMETRY, ALLOY 6061, 130mm TRAVEL, ALLOY ROCKER, DROPOUT 148x12mm BOOST, 29"
Fork ROCK SHOX 35 GOLD RL DEBONAIR 29", 15x110mm AXLE, TAPERED, 130mm TRAVEL, REBOUND, COMP.TO LOCK
Motor SHIMANO STEPS EP8, 250 WATT
Batteries DARFON, 36V, 630Wh
Display SHIMANO SC-E5003
Assistance levels ECO, TRAIL, BOOST
E-bike speed 25 km/h
Shock ROCK SHOX DELUX SELECT R, LEVER, DEBON AIR, 205mm, TRUNNION MOUNT, HARDWARE: 30mm x 8mm
Rear derailleur SHIMANO SLX RD-M7100 SGS SHADOW PLUS DESIGN, 12-SPEED
Shift lever SHIMANO SLX SL-M7100, DIRECT ATTACH TO BRAKE LEVER, ISPEC EV
Crankset SHIMANO STEPS FC-EM600, 34 TEETH
Cassette SHIMANO CS-M7100, 10-51 THEETH, 12-SPEED
Chain SHIMANO CN-M7100 12-Speed
Brakes SHIMANO BR-M6120, 4-PISTON HYDRAULIC DISC BRAKE, RESIN PADS, F:203mm, R:203mm ROTORS
Brake lever SHIMANO BL-M6100, ISPEC EV
Front hub SHIMANO HB-MT410-B, 32 HOLES, 15x110mm BOOST THRU AXLE
Rear hub SHIMANO FH-MT510-B, 32 HOLES, 12x148mm BOOST THRU AXLE
Front tire SCHWALBE NOBBY NIC EVO SUPER TRAIL, ADDIX SPEEDGRIP, TL EASY, 29x2.6"
Rear tire SCHWALBE HANS DAMPF EVO SUPER TRAIL, ADDIX SPEEDGRIP, TL EASY, 29x2.6"
Stem BIXS 0°ANGLE, 35mm CLAMP
Handlebar BIXS RIZER BAR, 780mm, 9° BACKSWEEP, 15mm RISE, 35mm
Headset FSA NO.57E, 1-1/8" UPPER AND 1.5" LOWER BEARING WITH 12.3mm TOP COVER
Seat post KIND SHOCK RAGEi, M: 100mm, L: 125mm, XL: 150mm TRAVEL, SHIMANO REMOTE LEVER, 30.9mm
Saddle ERGON SM10 E-MOUNTAIN SPORT MEN
Weight 24.9 KG

Geometry

Size A B C D E F G H I J K L
S 406 590 135 470 74° 66° 1196 40 633 408 340 165
M 445 595 140 470 74° 66° 1202 50 638 413 340 165
L 480 615 145 470 74° 66° 1223 60 643 431 340 165
XL 530 635 150 470 74° 66° 1243 70 648 450 340 165

A Frame size
B Top tube horizontal (mm)
C Head tube (mm)
D Chainstay length (mm)
E Seat tube angle
F Head tube angle
G Wheel base (mm)
H Stem (mm)
I Stack (mm)
J Reach (mm)
K Bottom bracket height (mm)
L Crank length (mm)
