Spezifikationen Sauvage-E25

Rahmen E-TRAIL GEOMETRY, ALLOY 6061, 150mm TRAVEL, ALLOY ROCKER, DROPOUT 148x12mm BOOST, 29"
Gabel ROCK SHOX YARI RC 29"/27.5"+, BOOST 15x110mm, TAPERED, 160mm TRAVEL, REBOUND, COMPRESSION TO LOCK
Motor SHIMANO STEPS EP8, 250 WATT
Batterien SIMPLO, 36V, 630Wh
Display SHIMANO SC-EM800
Unterstützungsstufen ECO, TRAIL, BOOST
E-Bike Speed 25 km/h
Dämpfer FOX FLOAT DPS PERFORMANCE, LV, EVOL, 3 POS, 205x65mm LENGTH, HARDWARE: 21.8mmx8mm
Schalthebel SHIMANO DEORE SL-M6100, CLAMP  TYPE
Kurbelgarnitur SHIMANO FC-EM600, 165MM, 34 TEETH
Kassette SHIMANO CS-M6100, 10-51 THEETH, 12-SPEED
Kette SHIMANO CN-M6100 12-SPEED
Bremshebel SHIMANO BL-MT501, ISPEC II
Nabe vorne SUNRINGLE WHEELSET DUROC COMP, 32 HOLES, 15x110mm THRU AXLE
Nabe hinten SUNRINGLE WHEELSET DOROC COMP, 32 HOLES, 12x148mm BOOST, THRU AXLE
Vorderreifen SCHWALBE MAGIC MARY EVO SUPER TRAIL, ADDIX SOFT, TL EASY, 29x2.4"
Hinterreifen SCHWALBE BIG BETTY EVO SUPER TRAIL, ADDIX SOFT, TL EASY, 29x2.4"
Vorbau BIXS 0°ANGLE, 35mm CLAMP
Lenker BIXS RIZER BAR, 780mm, 9° BACKSWEEP, 15mm RISE, 35mm
Steuersatz FSA NO.57E, 1-1/8" UPPER AND 1.5" LOWER BEARING WITH 12.3mm TOP COVER
Sattelstütze KIND SHOCK RAGEi, M & L: 125mm, XL: 150mm TRAVEL, SOUTHPAW-ALLOY REMOTE LEVER, 31.6mm
Sattel BIXS E-MTB
Gewicht 24.5 KG

Geometrie

Grösse A B C D E F G H I J K L
M 430 627 110 450 74° 66.5° 1214 40 608 450 360 165
L 460 637 115 450 74° 66.5° 1225 40 612 458 360 165
XL 500 647 120 450 74° 66.5° 1236 40 617 467 360 165

A Rahmengrösse
B Oberrohr horizontal mm
C Steuerrohr mm
D Kettenstreben mm
E Sitzwinkel Grad
F Radstand mm
G Radstand mm
H Vorbau mm
I Stack mm
J Reach mm
K Tretlagerhöhe mm
L Kurbellänge mm
