Splash-E12

Out of the city, up the mountain or to the lakeside, maybe even off-road. The Core-E is your versatile companion and offers enough reserve to leave the usual paths thanks to its 120 mm suspension travel. The powerful Shimano motor is by your side, known for its natural riding feeling. With its agile 27.5-inch wheels and cleverly angled top tube, the bike scores with its low standover height - perfect for smaller riders.

CHF 3,990.00

Unit price: per

Dark Petrol

Frame sizes
149 – 163 cm: S
159 – 178 cm cm: M
174 - 188 cm: L

Tax included. Shipping calculated at checkout.

Splash-E

Strong, self-confident and reduced to the essentials.

Learn more about the Splash-E +

Specifications Splash-E12

Frame	SPLASH-E PREMIUM ALLOY HARDTAIL, 12X148MM BOOST
Fork	SUNTOUR SF25-XCR34X DS AIR, 120MM TRAVEL, 15X110MM
Motor	SHIMANO EP600, 85NM
Batteries	DARFON 600WH, RANGE EXTENDER CAPABLE
Display	SHIMANO SC-EN500
Rear derailleur	SHIMANO CUES RD-U6000, 11-SPEED
Shift lever	SHIMANO CUES SL-U6000-11R
Crankset	SHIMANO FC-EM600, SM-CRE70-B, CL53, 34T
Cassette	SHIMANO CUES CS-LG400-11, 11-50T
Chain	SHIMANO CUES CN-LG500
Brakes	SHIMANO BL-M4100, BR-MT420 4-PISTON
Brake lever	FRONT: SHIMANO SM-RT30 CENTER LOCK, 203MM / REAR: SHIMANO RT-EM300 CENTER LOCK, 203MM
Rims	ALEXRIMS EM35, 35MM INNER WIDTH
Front hub	SHIMANO HB-TC500-15-B, 32 HOLES
Rear hub	SHIMANO FH-TC500-HM-B, 32 HOLES
Front tire	SCHWALBE SMART SAM PERFORMANCE, 27.5X2.6", ADDIX
Rear tire	SCHWALBE SMART SAM PERFORMANCE, 27.5X2.6", ADDIX
Stem	SATORI URSA, 0°, 35MM CLAMP
Handlebar	BIXS RIZER BAR, 25MM RISE, 760MM
Seat post	BIXS SEATPOST, Ø31.6MM, S & M: 3 50MM, L & X L: 400MM
Saddle	BIXS VL-4432
Headlight	LITEMOVE SE-70, 70 LUX
Rear light	INFINI TURBO 5 MODES BATTERY LIGHT
Weight	23.3 KG

Geometry

		S	M	L
A	Reach	407	425	444
B	Stack	645	654	655
C	Top Tube	580	600	620
D	Seat Tube	380	430	480
E	Head Tube	135	140	145
F	Fork Length	536	536	536
G	Fork Offset	44	44	44
H	Chainstay	455	455	455
I	Seat Angle	75	75	75
J	Head Tube Angle	67	67	67
K	BB Drop	45	45	45
L	BB Height	315	315	315
M	Wheelbase	1162	1183	1203
	Stem Length	50	50	50
	Crank Length	165	165	165
