Spécifications Mariposa EQ

Cadre WOMEN GEOMETRY, ALLOY 6061 HYDROF. T.B. HARDTAIL 27.5"
Fourche SUNTOUR NVX30, 27.5", QR, 100mm TRAVEL
Dérailleur arr. SHIMANO ACERA RD-M360 SGS TOP NORMAL, 8-SPEED
Dérailleur av. SHIMANO FD-M313, DOWN SWING, 34.9mm CLAMP
Levier de vitesse SHIMANO SL-M315, WITH OPTICAL GEAR DISPLAY
Pédalier SHIMANO TOURNEY FC-TX801, 42-32-22 TEETH
Pédale VP 872N
Roulement de pédalier SHIMANO BB-UN300-K, 68mm x 122.5mm
Cassette SHIMANO CS-HG31, 11-34 TEETH, 8-SPEED
Chaîne SHIMANO CN-HG40
Freins SHIMANO BR-MT200, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:180mm, R:160mm ROTORS
Levier de frein SHIMANO BL-MT201
Moyeu avant SHIMANO DH-3D32 HUB DYNAMO, 6V, 3W, 32 HOLES, QR
Moyeu arrière KT MD4R, 32 HOLES, QR
Pneu avant SCHWALBE BIG BEN, 27.5x1.95"
Pneu arrière SCHWALBE BIG BEN, 27.5x1.95"
Potence BIXS AS-M03, 0°ANGLE, 31.8mm CLAMP
Guidon BIXS HB-RB12L RIZER BAR, 720mm, 9°ANGLE, 25mm RISE, 31.8mm
Jeu de direction FSA NO.57B-1, 1-1/8" UPPER AND 1.5" LOWER BEARING WITH 8.2mm TOP COVER, FOR 1-1/8" STEERER
Tige de selle BIXS SP-3D2, XS: 300mm, S & M: 350mm, ORTHERS: 400mm, 31.6mm
Selle BiXS VL-3225
Feu arrière TRELOCK LS-613 LED, STANDLIGHT AUTOMATIC
Dynamo SHIMANO DH-3D32 HUB DYNAMO, 6V, 3W, 32 HOLES, QR
Porte-bagages RACKTIME, BiXS CUSTOM WITH CLAMP
Garde-boue BIXS CC-049, ALLOY FENDER, 61mm WIDE, 27.5"
Poids 16.2 KG

Géométrie

TailleABCDEFGHIJKL
XS35055010544073°69°105935598367300170
S38056011044073°69°107035603375300170
M43058012044073°69°109045613393300175
L48060013044073°69°111155622410300175

A Taille de cadre mm
B Long. tube horizontal mm
C Long. tube de dir. mm
D Long. bases arrières mm
E Angle tube de selle
F Angle tube de direction
G Base mm
H Potence mm
I Stack mm
J Reach mm
K Hauteur de pedalier mm
L Longueur des manivelles mm
