We use identical frames for both the Peak and the Lane. However, the two platforms differ significantly in their specifications. In general, we classify the Peak as a trail bike and the Lane as an enduro bike.

The Peak has a standard rear suspension travel of 140mm (damper stroke 57.5mm). Would you like more suspension travel? With a damper stroke of 65mm, you can increase the suspension travel to a maximum of 160mm.

The Peak is equipped with a suspension fork stroke of 150mm as a standard and is compatible from 150mm up to a maximum stroke of 170mm.

Wheel size: 29”
Tire clearance: 64mm, diameter 750mm
Wheel hub rear: 148x12mm Boost
Thru axle rear: Axle length: 180mm, thread: M12x1.0, thread length: 13mm
Chain line: 55mm
max. chainring size: 34t
Chain guide standard: ISCG05
Bottom bracket: BSA 73mm
Brake mount: Postmount 180mm
Shock mount: standard - standard
Exe-to-eye length: 230mm
Shock stroke length: 57.5mm
Shock hardware: 30x8mm / 20x8mm
Seat post: ø31.6mm
Seat clamp: ø34.9mm
max. seat post insertion depth S 200mm / M 230mm / L 250mm / XL 300mm
Bearing main pivot & rocker: ø28xø15x7 (6 pieces)
Bearing horst link: ø24xø12x6 (4 pieces)
Frame weight: 3,9 kg (incl. hardware, thru axle and frame protection, without damper, size S)
