Pace 100

Powerful, stiff and progressive. Trimmed for race performance, the PACE is on course to success and heading straight to the winners' podium. The carbon frame has been designed with the most modern geometry so the athletes are prepared for anything.

CHF 5,590.00

Unit price: per

Grey - Raw Carbon

Which size fits me?

Frame sizes
149 – 163 cm: S
159 – 178 cm cm: M
174 - 188 cm: L
185 - 200 cm: XL

Where to test and buy?

Pace

No friends on a Pace day.

Learn more about the Pace +

Specifications Pace 100

Frame	RACE GEOMETRY, FULL CARBON FRAME, 100mm TRAVEL, DROPOUT 148x12mm BOOST, 29"
Fork	FOX 34 FLOAT SC PERFORMANCE 29", 15x110mm AXLE, TAPERED, GRIP, 110mm TRAVEL, 3-POS. LEVER
Shock	FOX FLOAT DPS PERFORMANCE ELITE, LV, EVOL, 2 POS REMOTE, 165x40, TRUNNION MOUNT, HARDWARE: 25mmx8mm
Rear derailleur	SHIMANO XT RD-M8100 SGS SHADOW PLUS DESIGN, 12-SPEED
Shift lever	SHIMANO XT SL-M8100, DIRECT ATTACH TO BRAKE LEVER, ISPEC EV
Crankset	SHIMANO XT FC-M8100-1, HOLLOWTECH II, 32 TEETH
Bottom bracket	SHIMANO SM-BB93
Cassette	SHIMANO CS-M8100, 10-51 THEETH, 12-SPEED
Chain	SHIMANO CN-M8100 12-Speed
Brakes	SHIMANO XT BR-M8100, HYDRAULIC DISC BRAKE, RESIN PADS, F:180mm, R:180mm ROTORS
Brake lever	SHIMANO XT BL-M8100, ISPEC EV
Rims	DT SWISS WHEELSET SPLINE XM-1700, 28 HOLES, 30MM INNER WIDTH 29"
Front hub	DT SWISS WHEELSET SPLINE XM-1700, 28 HOLES, 15x110mmTHRU AXLE
Rear hub	DT SWISS WHEELSET SPLINE XM-1700, 28 HOLES, 12x148mm BOOST, THRU AXLE
Front tire	SCHWALBE RACING RAY EVO SUPER RACE, ADDIX SPEEDGRIP, TL EASY, 29x2.35"
Rear tire	SCHWALBE RACING RALPH EVO SUPER RACE, ADDIX SPEEDGRIP, TL EASY, 29x2.35"
Stem	RACE FACE AEFFECT, 6°ANGLE, 35mm CLAMP
Handlebar	RACE FACE AEFFECT R, 760mm, 20mm RISE, 8° BACKSWEEP, 35mm
Headset	STSF17 INTEGRATED WITH CABLE INTEGRAGTION AND CABLE ENTRY DUSTCAP 1.5" UPPER AND LOWER BEARING
Seat post	KIND SHOCK LEV SI, S: 100mm, M & L: 125mm, XL: 150mm TRAVEL, SHIMANO REMOTE LEVER, 31.6mm
Saddle	ERGON SR10 SPORT
Weight	12.2 KG

Geometry

	SIZE	S	M	L	XL
A	Reach	404	429	450	475
B	Stack	592	601	610	623
C	Top Tube	564	592	614	643
D	Seat Tube	380	420	460	500
E	Head Tube	90	100	110	125
F	Fork Length	520	520	520	520
G	Fork Offset	51	51	51	51
H	Chainstay	437	437	437	437
I	Seat Angle	75.5	75.5	75.5	75.5
J	Head Tube Angle	67.9	67.9	67.9	67.9
K	BB Drop	48	48	48	48
L	BB Height	324	324	324	324
M	Wheelbase	1114	1143	1167	1197
	Stem Length	60	70	80	90
	Crank Length	170	175	175	175
