Specifications Mariposa 100

Frame WOMEN GEOMETRY, ALLOY 6061 HYDROF. T.B, DROPOUT FOR 148x12mm BOOST,  27.5"
Fork ROCK JUDY SILVER TK 27.5", SOLO AIR SPRING, TAPERED, 15x110mm AXLE, 100mm TRAVEL, REBOUND, LOCKOUT
Rear derailleur SHIMANO DEORE RD-M6100 SGS SHADOW PLUS DESIGN, 12-SPEED
Shift lever SHIMANO DEORE SL-M6100, WITH OPTICAL GEAR DISPLAY
Crankset SHIMANO FC-MT510-1, 2-PIECE CRANKSET, 32 TEETH
Pedal WELLGO C-015
Bottom bracket SHIMANO SM-BB52
Cassette SUNRACE CS-MZ800, 11-51 THEETH, 12-SPEED
Chain SHIMANO CN-M6100 12-SPEED
Brakes SHIMANO BR-MT200, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:180mm, R:180mm ROTORS
Brake lever SHIMANO BL-MT201
Front hub SHIMANO HB-MT410-B, 32 HOLES, 15x110mm BOOST THRU AXLE
Rear hub NOVATEC D462SB-SL, 32 HOLES,  HG BODY, 12x148mm BOOST THRU AXLE
Front tire SCHWALBE RAPID ROB, K-GUARD 27.5x2.25"
Rear tire SCHWALBE RAPID ROB, K-GUARD 27.5x2.25"
Stem BIXS AS-M03, 0°ANGLE, 31.8mm CLAMP
Handlebar BIXS HB-RB12L RIZER BAR, 720mm, 9°ANGLE, 25mm RISE, 31.8mm
Headset FSA NO.57B, 1-1/8" UPPER AND 1.5" LOWER BEARING WITH 8.2mm TOP COVER
Seat post BIXS SP-3D2, S & M: 350mm, OTHERS: 400mm, 31.6mm
Saddle BiXS VL-3538
Weight 12.9 KG

Geometry

Size A B C D E F G H I J K L
S 380 560 110 440 73° 69° 1070 35 610 373 300 170
M 430 580 120 440 73° 69° 1090 45 620 390 300 175
L 480 600 130 440 73° 69° 1111 55 630 407 300 175

A Frame size
B Top tube horizontal (mm)
C Head tube (mm)
D Chainstay length (mm)
E Seat tube angle
F Head tube angle
G Wheel base (mm)
H Stem (mm)
I Stack (mm)
J Reach (mm)
K Bottom bracket height (mm)
L Crank length (mm)
