| Rahmen |
E-TRAIL GEOMETRY, CARBON, 150mm TRAVEL, ALLOY ROCKER, DROPOUT 148x12mm BOOST, 29" |
| Gabel |
FOX 36 FLOAT FACTORY, KASHIMA, 15x110mm, FIT4, TRAVEL: 160mm, 3-POSITION OPEN ADJ., 44mm OFFSET |
| Motor |
SHIMANO STEPS EP8, 250 WATT |
| Batterien |
SIMPLO, 36V, 630Wh |
| Display |
SHIMANO SC-EM800 |
| Unterstützungsstufen |
ECO, TRAIL, BOOST |
| E-Bike Speed |
25 km/h |
| Dämpfer |
FOX FLOAT DPS FACTORY, KASHIMA, LV EVOL, 3 POS LEVER 205x65, TRUNNION MOUNT, HARDWARE: 21.8mmx8mm |
| Schaltwerk |
SHIMANO XT RD-M8100 SGS SHADOW PLUS DESIGN, 12-SPEED |
| Schalthebel |
SHIMANO XT SL-M8100, DIRECT ATTACH TO BRAKE LEVER, ISPEC EV |
| Kurbelgarnitur |
SHIMANO FC-EM900, HOLLOWTECH, 34 TEETH |
| Kassette |
SHIMANO CS-M8100, 10-51 THEETH, 12-SPEED |
| Kette |
SHIMANO CN-M8100 12-Speed |
| Bremsen |
SHIMANO XT BR-M8120, 4-PISTON HYDRAULIC DISC BRAKE, RESIN PADS, F:203mm, R:203mm ROTORS |
| Bremshebel |
SHIMANO XT BL-M8100, ISPEC EV |
| Felgen |
DT SWISS WHEELSET SPLINE HX-1501 TLR, INNER WIDTH 30mm, 29" |
| Nabe vorne |
DT SWISS WHEELSET SPLINE HX-1501, 15x110mm THRU AXLE |
| Nabe hinten |
DT SWISS WHEELSET SPLINE HX-1501, 12x148mm BOOST, THRU AXLE |
| Vorderreifen |
SCHWALBE MAGIC MARY EVO SUPER TRAIL, ADDIX SOFT, TL EASY, 29x2.4" |
| Hinterreifen |
SCHWALBE BIG BETTY EVO SUPER TRAIL, ADDIX SOFT, TL EASY, 29x2.4" |
| Vorbau |
RACE FACE TURBINE R, 0°ANGLE, 35mm CLAMP |
| Lenker |
RACE FACE NEXT R CARBON, 780mm, 20mm RISE, 8° BACKSWEEP, 35mm |
| Steuersatz |
FSA NO.57E, 1-1/8" UPPER AND 1.5" LOWER BEARING WITH 12.3mm TOP COVER |
| Sattelstütze |
FOX TRANSFER FACTORY KASHIMA, M & L: 125mm, XL: 150mm TRAVEL, SHIMANO REMOTE LEVER, 31.6mm |
| Sattel |
ERGON SM10 E-MOUNTAIN SPORT MEN |
| Gewicht |
23.8 KG |
